60 tons Payload 3 Axles Bulk Cement Trailer For Sale With capacity 30 to 45 Cbm
I. Application:
Bulk cement bulker trailer is suitable for carrying bulk cement, coal ash, lime power, mineral power, fuly ash and other power material with the partice diameter no more than 0.1mm
II. Feature:
1. Tank body of bulk cement tanker trailers are made of high strenth wear-resistant steel, have lightweight and more durable.
2. The Bulk cement tanker trailer with no guide plate structure,have lighter weight,lower residue.
3. Wide area fluidized bed with a large angle tanker,so unloading faster and less residue
4. Linear arrangement of the intake inlet line is smoother,make the unloading faster.
III. Quality guarantee
1. More than 30 years experiences in trailer and truck industrial,exported to more than 30 countries in Africa,Southeast Asia.
2. Two years free warranty terms for the I beam,three to six month free warranty terms for the Axles,suspension etc.
3. Spare parts support services.
4. Able to custom-built design as your requirment,ensure to meet your local road regulation.
IV. Specification
| Style |
3 Axles Bulk Cement Tanker Trailer |
| Dimension(L*W*H) |
9800*2500*3700 (mm) /Custom-Built |
| Max. payload |
35000kgs to 60000 kgs |
| Volume |
30CBM / Optional |
| Tare weight |
9700 (kgs) |
| Kingpin |
JOST 3.5” bolt-in |
| Landing gear |
JOST 19” |
| Tire size |
12R22.5 (13sets) |
| Rim size |
9.00*22.5 (13sets) |
| Axle |
BPW brand ,3 axles,13 tons |
| Susupension |
Fuwa steel suspension with 9pcs of leafs spring |
| Brake system |
Dual line with WABCO brand Re-6 emergency relay valve, MBA brand T30/30 air chamber, 46L air tank |
| Electric system: |
One unit of 24V 7-pin ISO standard socket; with brake light, turn light, reverse light, side light, reflector, fog light; one set of 6-pin standard cable |
| Diesel Engine: |
Shandong WeiChai 4100(40KW)(2000r/min) |
| Air compression: |
SuZhou WBF-10/2 (10M3/min) (0.2MPA) |
| Painting |
Zinc-rich & Polyurethane painting |
Product Tags:
|
|
3 Axles Bulk Cement Tanker Trailer 60 Tons Payload High Strength Steel Tank Body Images
|
